Stainless Pipe A312 GR.TP304L,EFW,PE,36.19,SCH.10S 18in

ASTM A312 312M standardThis specificationcovers seamless, straight-seam welded, and heavily cold worked welded austeni

Send Inquiry

Product Introduction

ASTM A312/312M standard

This specification covers seamless, straight-seam welded, and heavily cold worked welded austenitic stainless steel pipe intended for high-temperature and general corrosive service.

Main Steel Grades - TP 304, TP 304L, TP 316, TP 321

Chemical Composition (%, max)
Steel Grade	C	Si	Mn	Cr	Ni	Mo	S	P
TP304	0,08	0,75	2	18 - 20	8 - 11	-	0,03	0,04
TP304L	0,035	0,75	2	18 - 20	8 - 13	-	0,03	0,04
TP316	0,08	0,75	2	16 - 18	11 - 14	2 - 3	0,03	0,04
TP316L	0,035	0,75	2	16 - 18	10 - 15	2 - 3	0,03	0,04
TP321	0,08	0,75	2	17 - 20	9 - 13	-	0,03	0,04

Mechanical properties
Steel Grade	Tensile Strength, N/mm2 (min)	Yield Strength, N/mm2 (min)	Elongation, % (min)
TP304	515	205	35
TP304L	485	170	35
TP316	515	205	35
TP316L	485	170	35
TP321	OD < 17,1 mm - 515; OD > 17,1 mm - 485	OD < 17,1 mm - 205; OD > 17,1 mm - 170	35

ASTM A213 TP 304L stainless pipe

TP304L Stainless Steel Pipe is widely used in petroleum, chemical, medical, food, light industry, machinery, instrument and other industrial pipeline and mechanical structure parts, etc. In addition, in bending and torsion strength, the weight is lighter, so it is also widely used to make mechanical parts and engineering structures.
