610mm Diameter Wallthickness 20mm Seamless Line Pipes

Product NameCarbon steel seamless line PipeUsageUsed for low pressure liquid delivery, such as water, gas, and oil

Product Introduction

Product Name	Carbon steel seamless line Pipe
Usage	Used for low pressure liquid delivery, such as water, gas, and oil.
Process	Hot rolled seamless pipes Hot expension seamless pipes
Standard	API 5L, ASTM A106, ASTM A53 EN10217, DIN 2458. IS 3589, GB/T3091, GB/T9711
Certificate	API 5L PSL1 / PSL2
Out Diameter	457mm– 914mm
Wall Thickness	8 -50mm
Length	up to 12m
Steel Grade
API 5L PSL1 / PSL2	GR B, X42, X46, X52, X56, X60, X65, X70, X80
ASTM A53	GR A, GR B, GR C
EN	S275, S275JR, S355JRH, S355J2H
GB	L210, L245, L320, L360- L555
Surface	Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black Oil coating as per customer’s requirement
Test	Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test.
Mill Test Certificate	EN 10204/3.1B
