EN 10025-3-2019 S355NL Low Alloy High Strength Steel Plate
DescriptionS355NL is a hot rolled, medium tensile, low carbon manganese steel which is readily weldable and posses
Product Introduction
Description
S355NL is a hot rolled, medium tensile, low carbon manganese steel which is readily weldable and possess good impact resistance (also in sub-zero temperatures).
This material is commonly supplied in the untreated or normalized condition and is available in several variations (denoted by additional letters and/or digits) which offer slight modifications of chemical composition and mechanical properties.
We have a large inventory of BS EN 10025-3 S355nl plate in almost all length, view S355NL Steel Plate price
S355NL Steel Plate Chemical Structure
C % |
Si % |
Mn % |
P % |
S % |
V % |
AL % |
Cr % |
0.180 |
0.500 |
0.9- 1.65 |
0.025 |
0.020 |
0.120 |
0.020 |
0.300 |
Cu % |
Mo % |
Nb % |
Ni % |
Ti % |
N % |
||
0.550 |
0.100 |
0.050 |
0.300 |
0.050 |
0.015 |
Mechanical Property Of S355NL Plate
Thickness(mm) |
Min Yield (Mpa) |
Tensile(MPa) |
Elongation(%) |
Min Impact Energy |
|
8mm-100mm |
235Map-275Mpa |
470-630Mpa |
22% |
-50 |
27J |
101mm-200mm |
285Mpa-315Mpa |
450-600Mpa |
21% |
-50 |
27J |
201mm-250mm |
275Mpa-285Mpa |
450-600Mpa |
21% |
-50 |
27J |
The min impact energy is longitudinal energy |
S355NL Structural Plates Equivalent Grades
Germany DIN,WNr |
France AFNOR |
England BS |
Italy UNI |
China GB |
Russia GOST |
TStE355 |
E 355 FP |
50EE |
Fe E 355 KT N |
|
1. Impact Temperature
S355N: Steel plate with an impact test temperature of -20°C.
S355NL: Steel plate with an impact test temperature of -50°C.
S355ML: Steel plate with an impact test temperature of -50°C.
2. Application Fields
S355N: Mainly used in large ships, bridges, power station equipment, medium/high-pressure boilers, high-pressure vessels, railway vehicles, lifting machinery, mining machinery, and other large welded structural components.
S355NL: Commonly applied in mining machinery, chemical machinery, agricultural machinery, wind power projects, metallurgical machinery, construction machinery, road machinery, and large steel structures. In China, S355NL steel plates are mostly used for export trade or manufacturing export equipment.
S355ML: Widely used in metallurgical machinery equipment manufacturing and electromechanical equipment manufacturing. Also suitable for load-bearing parts of welded structures in low-temperature environments, such as bridges, sluices, storage tanks, and water supply tanks.
